塑膠長期代理德國巴斯夫PA6 B3ZG6
因塑料行情每天都會有變更，請來電或在線QQ咨詢，謝謝！
本公司專業供應PA6各種品牌型號，可免費提供產品的物性，F(xiàn)DA、MSDS、SGS、REACH、ROHS、UL黃卡等，相關報告及材質證明；提供各種塑膠原料的鑒定與加工技術支持，歡迎新老客戶來電咨詢，我們竭誠為您服務?。?！ 銷售技術咨詢：謝先生：13829171386 QQ294189644
Ultramid PA6德國巴斯夫B3EG7玻纖35% 絕緣性好 阻燃HB
Ultramid PA6德國巴斯夫B3ZG6 B3EG6玻纖30% 高剛性 尺寸穩定 阻燃HB
Ultramid PA6德國巴斯夫B3EG3玻纖15% 高剛性 尺寸穩定 阻燃HB
Ultramid PA6德國巴斯夫B3WG3玻纖15% 阻燃HB
Ultramid PA6德國巴斯夫B3WG6玻纖30% 高剛性 尺寸穩定 阻燃HB
Ultramid PA6德國巴斯夫B3WG7玻纖35% 阻燃HB 高剛性 尺寸穩定
Ultramid PA6德國巴斯夫B36FN 高速透明
Ultramid PA6德國巴斯夫B3S、B30S、標準級，高流動
Ultramid PA6德國巴斯夫B3K B3UG4 B3UGM210 B3ZG6 B3WM602, E3120 BK
PA66性質：結晶性熱可塑性塑料，有明顯熔點，Nylon6 Tm為220-230℃，Nylon66則為260-270℃
PA6 B3WG6 物性表
| Rheological properties | dry / cond | Unit | Test Standard |
| Melt volume-flow rate, MVR | 30 / * | cm3/10min | ISO 1133 |
| Temperature | 275 / * | °C | ISO 1133 |
| Load | 5 / * | kg | ISO 1133 |
| Molding shrinkage, parallel | 0.3 / * | % | ISO 294-4, 2577 |
| Molding shrinkage, normal | 0.8 / * | % | ISO 294-4, 2577 |
| Mechanical properties | dry / cond | Unit | Test Standard |
| Tensile Modulus | 9500 / 6200 | MPa | ISO 527-1/-2 |
| Stress at break | 185 / 115 | MPa | ISO 527-1/-2 |
| Strain at break | 3.5 / 8 | % | ISO 527-1/-2 |
| Charpy impact strength, +23°C | 95 / 110 | kJ/m2 | ISO 179/1eU |
| Charpy impact strength, -30°C | 80 / 85 | kJ/m2 | ISO 179/1eU |
| Charpy notched impact strength, +23°C | 15 / 30 | kJ/m2 | ISO 179/1eA |
| Charpy notched impact strength, -30°C | 11 / 10.2 | kJ/m2 | ISO 179/1eA |
| Thermal properties | dry / cond | Unit | Test Standard |
| Melting temperature, 10°C/min | 220 / * | °C | ISO 11357-1/-3 |
| Temp. of deflection under load, 1.80 MPa | 210 / * | °C | ISO 75-1/-2 |
| Temp. of deflection under load, 0.45 MPa | 220 / * | °C | ISO 75-1/-2 |
| Vicat softening temperature, 50°C/h 50N | 220 / * | °C | ISO 306 |
| Coeff. of linear therm. expansion, parallel | 22.5 / * | E-6/K | ISO 11359-1/-2 |
| Coeff. of linear therm. expansion, normal | 65 / * | E-6/K | ISO 11359-1/-2 |
| Burning Behav. at 1.5 mm nom. thickn. | HB / * | class | IEC 60695-11-10 |
| Thickness tested (1.5) | 1.5 / * | mm | IEC 60695-11-10 |
| Yellow Card available | Yes / * | - | - |
| Burning Behav. at thickness h | HB / * | class | IEC 60695-11-10 |
| Thickness tested (h) | 0.7 / * | mm | IEC 60695-11-10 |
| Yellow Card available | Yes / * | - | - |
| Oxygen index | 22.5 / * | % | ISO 4589-1/-2 |
| Electrical properties | dry / cond | Unit | Test Standard |
| Relative permittivity, 1MHz | 3.8 / 6.8 | - | IEC 60250 |
| Dissipation factor, 100Hz | 230 / 2200 | E-4 | IEC 60250 |
| Dissipation factor, 1MHz | 230 / 2200 | E-4 | IEC 60250 |
| Volume resistivity | 1E13 / 1E10 | Ohm*m | IEC 60093 |
| Surface resistivity | * / 1E10 | Ohm | IEC 60093 |
| Electric strength | 41 / 31 | kV/mm | IEC 60243-1 |
| Comparative tracking index | - / 450 | - | IEC 60112 |
| Other properties | dry / cond | Unit | Test Standard |
| Water absorption | 6.6 / * | % | Sim. to ISO 62 |
| Humidity absorption | 2.1 / * | % | Sim. to ISO 62 |
| Density | 1360 / - | kg/m3 | ISO 1183 |
| Material specific properties | dry / cond | Unit | Test Standard |
| Viscosity number | 140 / * | cm3/g | ISO 307, 1157, 1628 |
| Rheological calculation properties | Value | Unit | Test Standard |
| Thermal conductivity of melt | 0.21 | W/(m K) | - |
| Spec. heat capacity melt | 2130 | J/(kg K) | - |
| Ejection temperature | 160 | °C | - |
| Test specimen production | Value | Unit | Test Standard |
| Injection Molding, melt temperature | 280 | °C | ISO 294 |
| Injection Molding, mold temperature | 80 | °C | ISO 10724 |
| Injection Molding, injection velocity | 200 | mm/s | ISO 294 |
