以下是PA66 Zytel ST801 NC010A中英文物性表
|
DuPont Zytel? ST801 NC010A Nylon 66（聚酰胺-尼龍66）
The property table is provided by www.plas-cn.com, welcome to download, reprint please indicate the source!
|
|||
|
Physical Properties物理性質
|
Metric公制數據
|
English英制數據
|
Comments測試方法
|
|
Density密度
|
1.08 g/cc
|
0.0390 lb/in3
|
DAM; ISO 1183
|
|
Water Absorption吸水率
|
2.2 %
@Temperature 23.0 °C |
2.2 %
@Temperature 73.4 °F |
Equilibrium 50%RH; DAM; ISO 62, Similar to
|
|
6.7 %
@Temperature 23.0 °C |
6.7 %
@Temperature 73.4 °F |
Saturation, immersed; DAM; ISO 62, Similar to
|
|
|
Viscosity 粘度
|
38000 cP
@Shear Rate 7000 1/s, Temperature 315 °C |
38000 cP
@Shear Rate 7000 1/s, Temperature 599 °F |
DAM; ISO 11443
|
|
88000 cP
@Shear Rate 7000 1/s, Temperature 275 °C |
88000 cP
@Shear Rate 7000 1/s, Temperature 527 °F |
DAM; ISO 11443
|
|
|
135000 cP
@Shear Rate 1000 1/s, Temperature 295 °C |
135000 cP
@Shear Rate 1000 1/s, Temperature 563 °F |
DAM; ISO 11443
|
|
|
181000 cP
@Shear Rate 500 1/s, Temperature 295 °C |
181000 cP
@Shear Rate 500 1/s, Temperature 563 °F |
DAM; ISO 11443
|
|
|
244000 cP
@Shear Rate 700 1/s, Temperature 275 °C |
244000 cP
@Shear Rate 700 1/s, Temperature 527 °F |
DAM; ISO 11443
|
|
|
283000 cP
@Shear Rate 500 1/s, Temperature 275 °C |
283000 cP
@Shear Rate 500 1/s, Temperature 527 °F |
DAM; ISO 11443
|
|
|
Linear Mold Shrinkage, Flow線性收縮率/流動
|
0.017 cm/cm
@Thickness 2.00 mm |
0.017 in/in
@Thickness 0.0787 in |
Parallel; DAM; ISO 294-4
|
|
Mechanical Properties力學性能
|
Metric公制數據
|
English英制數據
|
Comments測試方法
|
|
Tensile Stress拉伸應力
|
0.000 MPa
@Strain 0.000 %, Temperature -20.0 °C |
0.000 psi
@Strain 0.000 %, Temperature -4.00 °F |
50%RH; ISO 527
|
|
1410 psi
@Strain 5.01 %, Temperature 248 °F |
50%RH; ISO 527
|
||
|
19.8 MPa
@Strain 8.58 %, Temperature 90.0 °C |
2870 psi
@Strain 8.58 %, Temperature 194 °F |
DAM; ISO 527
|
|
|
29.76 MPa
@Strain 21.98 %, Temperature 60.0 °C |
4316 psi
@Strain 21.98 %, Temperature 140 °F |
DAM; ISO 527
|
|
