| TYPICAL PROPERTIES (1) |
| MECHANICAL |
Value |
Unit |
Standard |
| Tensile Stress, yld, Type I, 50 mm/min |
630 |
kgf/cm² |
ASTM D 638 |
| Tensile Stress, brk, Type I, 50 mm/min |
700 |
kgf/cm² |
ASTM D 638 |
| Tensile Strain, yld, Type I, 50 mm/min |
7 |
% |
ASTM D 638 |
| Tensile Strain, brk, Type I, 50 mm/min |
125 |
% |
ASTM D 638 |
| Flexural Stress, yld, 1.3 mm/min, 50 mm span |
980 |
kgf/cm² |
ASTM D 790 |
| Flexural Modulus, 1.3 mm/min, 50 mm span |
23900 |
kgf/cm² |
ASTM D 790 |
| Hardness, Rockwell M |
70 |
- |
ASTM D 785 |
| Hardness, Rockwell R |
118 |
- |
ASTM D 785 |
| Taber Abrasion, CS-17, 1 kg |
10 |
mg/1000cy |
ASTM D 1044 |
| IMPACT |
Value |
Unit |
Standard |
| Izod Impact, unnotched, 23°C |
326 |
cm-kgf/cm |
ASTM D 4812 |
| Izod Impact, notched, 23°C |
70 |
cm-kgf/cm |
ASTM D 256 |
| Tensile Impact, Type S |
557 |
cm-kgf/cm² |
ASTM D 1822 |
| Falling Dart Impact (D 3029), 23°C |
1728 |
cm-kgf |
ASTM D 3029 |
| Instrumented Impact Energy @ peak, 23°C |
633 |
cm-kgf |
ASTM D 3763 |
| THERMAL |
Value |
Unit |
Standard |
| Vicat Softening Temp, Rate B/50 |
154 |
°C |
ASTM D 1525 |
| HDT, 0.45 MPa, 6.4 mm, unannealed |
137 |
°C |
ASTM D 648 |
| HDT, 1.82 MPa, 6.4 mm, unannealed |
129 |
°C |
ASTM D 648 |
| CTE, -40°C to 95°C, flow |
6.84E-05 |
1/°C |
ASTM E 831 |
| Specific Heat |
1.25 |
J/g-°C |
ASTM C 351 |
| Thermal Conductivity |
0.25 |
W/m-°C |
ASTM C 177 |
| Relative Temp Index, Elec |
130 |
°C |
UL 746B |
| Relative Temp Index, Mech w/impact |
130 |
°C |
UL 746B |
| Relative Temp Index, Mech w/o impact |
130 |
°C |
UL 746B |
| PHYSICAL |
Value |
Unit |
Standard |
| Specific Gravity |
1.2 |
- |
ASTM D 792 |
| Specific Volume |
0.83 |
cm³/g |
ASTM D 792 |
| Density |
1.19 |
g/cm³ |
ASTM D 792 |
| Water Absorption, 24 hours |
0.15 |
% |
ASTM D 570 |
| Water Absorption, equilibrium, 23C |
0.35 |
% |
ASTM D 570 |
| Water Absorption, equilibrium, 100°C |
0.58 |
% |
ASTM D 570 |
| Mold Shrinkage, flow, 3.2 mm (5) |
0.5 - 0.7 |
% |
SABIC Method |
| Melt Flow Rate, 300°C/1.2 kgf |
17.5 |
g/10 min |
ASTM D 1238 |
| OPTICAL |
Value |
Unit |
Standard |
| Light Transmission, 2.54 mm |
88 |
% |
ASTM D 1003 |
| Haze, 2.54 mm |
1 |
% |
ASTM D 1003 |
| Refractive Index |
1.586 |
- |
ASTM D 542 |
| ELECTRICAL |
Value |
Unit |
Standard |
| Volume Resistivity |
>1.E+17 |
Ohm-cm |
ASTM D 257 |
| Dielectric Strength, in air, 3.2 mm |
14.9 |
kV/mm |
ASTM D 149 |
| Relative Permittivity, 50/60 Hz |
3.17 |
- |
ASTM D 150 |
| Relative Permittivity, 1 MHz |
2.96 |
- |
ASTM D 150 |
| Dissipation Factor, 50/60 Hz |
0.0009 |
- |
ASTM D 150 |
| Dissipation Factor, 1 MHz |
0.01 |
- |
ASTM D 150 |
| Hot Wire Ignition {PLC) |
2 |
PLC Code |
UL 746A |
| High Voltage Arc Track Rate {PLC} |
2 |
PLC Code |
UL 746A |
| High Ampere Arc Ign, surface {PLC} |
1 |
PLC Code |
UL 746A |
| Comparative Tracking Index (UL) {PLC} |
2 |
PLC Code |
UL 746A |
| FLAME CHARACTERISTICS |
Value |
Unit |
Standard |
| UL Recognized, 94HB Flame Class Rating (3) |
0.71 |
mm |
UL 94 |
| Radiant Panel Listing |
YES |
- |
UL Tested |
| UV-light, water exposure/immersion |
F2 |
- |
UL 746C |
